ASI 10-110-1 Recessed Toilet Tissue Holder, Chase Mount, Square
ASI 10-110-1 Fabricated of 14 gauge type 304 stainless steel with satin finish exterior, glass blasted satin finish interior 4-1/2" (114 mm) deep accommodates one standard toilet tissue roll. Flange is 7" (179 mm) square.
| Overall Dimensions:: | 7" Wide x 7" Tall x 4-1/2" Depth |
| Shipping Weight: | 2.8 lbs |
| Manufacturer Model No.: | 10-110-1 |
Architectural Specifications:
Recessed Toilet Paper Holder with square bezel for chase mounting shall hold one (1) standard toilet paper roll and shall be 14 gage type 304 stainless steel alloy 18-8. Beveled trim shall have satin finish. Two (2) anchor 1/4-20 T-nuts are welded to holder back. Back mounting plate shall be 11 gage die-formed galvanized steel. Hardware mounting kit (supplied) shall include two (2) threaded rods 1/4-20 x 8" [204] long with four (4) each washers and nuts, back mounting plate and two (2) bolts 1/4-20 x 3/4" [19] long to hold back mounting plate in place. Orientation of threaded rods and bolts shall accommodate shallow or deep wall installation.
