ASI 10-7322 Stainless Steel Wire Soap Basket, Corner Mount, Satin Finish
Surface Mounted Clothes Hook are fabricated of alloy 18-8 stainless steel, type 304. Hook is formed from one piece of No. 11 gauge stainless steel and projects 1-1/4" (32mm) from mounting surface with a 1/2" (13mm) hook tip. A 1-1/4" (32mm) square stainless steel safety dress plate with radiused corners is aligned and welded to hook tip. Two (2) 7/32" (5.6mm) dia. holes are provided to accommodate mounting screws.
All exposed surfaces are No. 4 satin finish.
| Primary Material: | Stainless Steel |
| Mount: | Corner / Surface |
| Capacity: | 10 lbs. |
| Overall Dimensions: | 11-15/32" Wide x 2-9/32" Tall x 6-1/2" Deep |
| Net Weight: | 1.15 lbs. |
| Shipping Dimensions: | 12-1/2" Length x 7-1/4" Width x 3-1/4" Height |
| Shipping Weight: | 1.35 lbs. |
| UPC / GTIN: | Not published |
| Warranty: | Warranted to be free from initial defects in material and workmanship for a period of one (1) year from date of invoice. |
| Country of Manufacture: | Not published Buy American Act compliant |
| Comments: | Mounting hardware included. |
Architectural Specifications:
Soap Basket shall be type 304 stainless steel alloy 18-8 of welded formed round wire construction and shall be fabricated with heavy gauge solid rectangular cross section formed bar top rim. Support posts shall be 3/8" diameter (Ø10) solid rod with polished cast mounting flange bolted on. Finish shall be satin on all visible surfaces. A stainless steel setscrew shall be provided on bottom perimeter of flanges to lock unit to mounting plates. Mounting plates provided shall be formed 19 gauge with integral ribs for rigid installation.
