Bobrick 3974-350 Convertible Automatic, Universal Roll Paper Towel Dispenser Module Equipped with Intuitive LED Light
Automatic (hands-free) commercial roll-type paper towel dispenser in modular stainless steel cabinet. Adds automatic functionality (or replaces/repairs existing manual or pull type unit). Battery operated. Easy to install or swap out. For use with Bobrick B-3974, B-3979 and B-39747 modular towel dispensers with waste receptacles.
- Accommodates easily available universal roll paper towels to reduce cost and waste.
- Trigger bar technology and adjustable sensor range virtually eliminates unintentional dispensing.
- Adjustable dispense length and concealed or exposed paper option.
- LED indicator on front indicates readiness to dispense, paper towel supply, and battery level.
- Quieter operation and dispensing.
- Unmatched reliability with 99.99% jam free operation.
Measurement Diagram:
| Type: | Automatic, Roll Type Commercial Paper Towel Dispenser Module |
| Primary Material: | Stainless Steel |
| Color / Finish: | Brushed Finish |
| Installation Type: | Modular Insert (may be surface mounted, see additional comments below) |
| Capacity: | 1 Stanadard Commercial Paper Towel Roll & 1 4" Stub Roll |
| Power: | 3974-350 |
| ADA Compliant: | Not ADA for hallway (Projects more than 4") |
| Overall Dimensions: | Not Published |
| Rough-In: | 1 Yr. Manufacturer's Limited |
| Shipping Dimensions: | 23" Length x 18" Width x 12" Height |
| Shipping Weight: | 16 lbs. |
| Manufacturer Model No.: | 3974-350 |
| UPC / GTIN: | Not published |
| Compatibility: | Bobrick B-3974, B-3979 Convertible Paper Towel Dispensers May also be surface mounted (see additional comments below) |
| Warranty: | 1 Yr. Manufacturer's Limited |
| Additional Comments: | To surface mount, use Bobrick part: 3949-57 - 4" Skirt for Surface Mounting |
Architectural Specifications:
Convertible automatic universal roll paper towel module shall be Type-304 stainless steel with all-welded construction; exposed surfaces shall have satin-finish. Door shall be secured to cabinet with a full-length stainless steel piano-hinge and equipped with a concealed tumbler lock keyed like other Bobrick washroom accessories. No-touch dispenser, equipped with an intuitive LED light to direct patrons to the dispense area, dispenses universal, 1-1/2" to 2" (38 to 51mm) diameter core, up to 8" (205mm) diameter, 8" (205mm) wide, non-perforated, nonproprietary paper towel rolls, 800 ft (244 m) long. Dispenser automatically dispenses towel when hands are placed under the towel opening. Dispenser can be powered by 4 “D” size alkaline batteries or an optional 6 volt AC to DC power supply. Equipped with switches that allow paper length to be set at 9" (230mm), 12" (305mm) or 15" (380mm) and “Paper Saver” feature that provides a shorter second sheet with options of 25%shorter and 12.5% shorter. LED light at the towel opening flashes green when dispenser is ready to dispense, flashes orange, indicating low battery, flashes red if not ready to dispense or in need of service. Automatic transfer shall dispense stub roll up to 3-1/2" (90mm) diameter before new main roll is automatically dispensed.
