Sloan 3070026 Gem-2 111-1.28-XL Manual Water Closet (Toilet) Flushometer, 1.28 gpf, Top Spud
Sloan GEM-2 111-1.28-XL Series concealed manual flushometer for toilets. 1.28 gallons per flush. Polished chrome finish. Polished chrome finish. ADA compliant, non-hold-open handle and no external volume adjustment to ensure water conservation.
1-1/2" Spud coupling and flange for 1-1/2" top spud toilet fixtures. 1" supply pipe, and 1" control stop.
Valve type: diaphragm with relief valve.
PERMEX synthetic rubber dual filtered fixed bypass diaphragm for improved life and lower maintenance. Longer lifespan from semi-red brass construction and high copper, low zinc brass castings for de-zincification resistance.
- Sweat solder adapter with cover tube and cast wall flange with set screw.
- Diaphragm, handle packing and vacuum breaker molded from PERMEX rubber compound for Chloramine resistance
- 11-1/2" Rough-in
- 1” I.P.S. Screwdriver Bak-Chek Angle Stop with Free Spinning Vandal Resistant Stop Cap
- WaterSense compliant when used with a 1.28 gpf WaterSense fixture
Measurement Diagram:
| Type: | Water Closet (Toilet) Flushometer, Manual |
| Brand: | Sloan |
| Model No.: | 3070026 (GEM-2 111-1.28-XL) |
| Primary Material: | Semi-red Brass |
| Color / Finish: | Polished Chrome |
| Operation: | Manual (Handle) |
| Flush Volume: | 1.28 gpf |
| Fixture Connection: | Top Spud |
| Supply Pipe: | 1" diameter |
| Valve Type: | Piston |
| Power Type: | None (Manual) |
| Rough-in Dimension: | 11-1/2" |
| Spud Coupling: | 1-1/2" |
| Valve Operating Pressure: | 15 – 80 PSI (103 – 552 kPa). Specific toilet fixtures may require greater minimum flowing pressure - consult manufacturer requirements. |
| Override: | N/A |
| Shipping Dimensions: | 18" Length x 12" Width x 6" Height |
| Shipping Weight: | 6 lbs. |
| UPC / GTIN: | 671254393134 |
| Country of Manufacture: | United States |
| Additional Comments: | 3 Yr. Manufacturer's Warranty |
