Zurn ZER6000PL-HET-CPM AquaFlush® PLUS Automatic Toilet Flush Valve, 1.28 GPF, 11.5" Valve Height, Non-mechanical Flush Override
The ZER6000PL-HET-CPM is an automatic flush valve for water closets (toilets). 1.28 GPF (Gallons per Flush). AquaFlush Plus are furnished with a sweat solder kit, vandal resistant stop cap, and cast wall flange with set screw. Internal seals are made of chloramine resistant materials. This flush valve features an exposed, quiet diaphragm-type, chrome plated, flushometer valve with a polished exterior. Complete with Zurn's 1.28 gpf AquaVantage® TPE chloramine resistant, dual seal diaphragm with a clog resistant by-pass. The valve incorporates a 6VDC motor actuator, a battery powered automatic sensor, high impact resistant polycarbonate housing and chrome plated metal cover with (non-mechanical) manual override push button and 10 degree angled sensor, high back pressure vacuum breaker, one piece hex coupling nut, adjustable tailpiece, spud coupling and flange for top spud connection. Control stop has internal siphon-guard protection.
AquaFlush Plus unit - includes the AquaFlush diaphragm kit with vandal resistant control stop
Clog-resistant diaphragm
Chrome-plated metal E-Z Flush sensor unit with 3-year battery life
Chemical resistant gaskets and seals for extended service life with lower maintenance costs
Zurn Limited 3-year warranty
Certifications:
Measurement Diagram:
| Brand: | Zurn AquaFlush® |
| Manufacturer Model No: | ZER6000PL-HET-CPM |
| For Use With: | Water Closet (Toilet) |
| Operation: | Automatic |
| Flush Override: | Non-mechanical |
| Gallons Per Flush (GPF): | 1.28 |
| Construction: | Exposed, quiet diaphragm-type, chrome plated, flushometer valve with a polished exterior. Complete with Zurn's 1.28 gpf AquaVantage® TPE chloramine resistant, dual seal diaphragm with a clog resistant by-pass. |
| Overall Dimensions: | 8" Wide x 13.5" Tall x 5" Deep |
| Shipping Dimensions: | 17" Length x 10.8" Width x 5.5" Height |
| Shipping Weight: | 11 lbs. |
| UPC / GTIN: | 670240385405 |
| Country of Manufacture: | USA |
| Warranty: | 3 Year Zurn Limited |
Warnings:
 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
Architectural Specifications:
Exposed, quiet diaphragm-type, chrome plated, flushometer valve with a polished exterior. Complete with Zurn's 1.28 gpf AquaVantage® TPE chloramine resistant, dual seal diaphragm with a clog resistant by-pass. The valve incorporates a 6VDC motor actuator, a battery powered automatic sensor, high impact resistant polycarbonate housing and chrome plated metal cover with manual override push button and 10 degree angled sensor, high back pressure vacuum breaker, one piece hex coupling nut, adjustable tailpiece, spud coupling and flange for top spud connection. Control stop has internal siphon-guard protection. The AquaFlush® Plus is also furnished with a sweat solder kit, vandal resistant stop cap, and cast wall flange with set screw. Internal seals are made of chloramine resistant materials.
